DOI: 10.1055/a-2512-0861
Three-point traction functions like full-face traction: facilitating rapid excision of a laterally spreading tumor
With the progression of technology, endoscopic submucosal dissection (ESD) has been increasingly applied in clinical practice. However, ESD still faces technical challenges in certain cases. To reduce the difficulty of the procedure, shorten the operation time, and decrease the incidence of complications, various traction devices have been invented and employed clinically [1] [2] [3]. Additionally, owing to limitations of single-point traction, multipoint traction techniques have been developed to achieve more efficient dissection. These multipoint traction techniques represent technological improvements and innovations based on traction devices [4] [5]. Herein, we introduce a novel multipoint traction method that enhances traction force, enabling rapid dissection of the lesion.
A 55-year-old woman underwent colonoscopy, during which a laterally spreading tumor measuring approximately 2.2 × 1.8 cm was identified in the mid-transverse colon ([Fig. 1] a). Subsequently, she underwent ESD ([Video 1]). ESD was considered challenging due to the lesion extending over intestinal folds and being influenced by arterial pulsation. Therefore, we employed a novel multipoint traction method to address these difficulties.


Quality:
First, a circumferential mucosal incision was made using a mucosal cutting knife ([Fig. 1] b). An elastic rubber ring was then knotted in the middle to form an “8” shape. One loop of the rubber ring was secured to the right side of the lesion using a clip ([Fig. 1] c). A second clip was used to anchor the opposite loop of the rubber ring to the left side of the lesion ([Fig. 1] d). The central part of the rubber ring was then fixed at the anal side of the lesion with a third clip ([Fig. 1] e). A fourth clip was applied to the middle of the rubber ring, securing it to the opposite intestinal wall ([Fig. 1] f). Following this traction technique, the submucosal layer was clearly exposed, transitioning from point traction to surface traction. This increased the traction area and achieved a converging effect. Benefiting from the tension generated by the traction device, the endoscopist successfully completed the dissection of the entire submucosal layer within 2 minutes ([Fig. 1] g), without causing damage to the muscularis propria. The resected lesion measured approximately 2.8 × 2.2 cm ([Fig. 1] h). Postoperative pathology revealed a tubular adenoma with low grade dysplasia, with no tumor tissue observed at the horizontal and basal margins.
This novel multipoint traction method not only converges the lesions from both sides but also utilizes three traction points to pull the lesion toward the opposite side of the intestinal lumen, creating a fan-like convergence. This approach offers two primary advantages: it reduces the area of the lesion that needs to be dissected and ensures consistent tension throughout the submucosal layer, facilitating rapid dissection. However, we are considering whether an alternative setup with the third clip securing both loops at the anal side of the lesion, or the fourth clip similarly securing both loops on the opposite intestinal wall, might yield even better results. We will continue to explore and study this possibility.
In summary, our new multipoint traction method provides valuable insights for endoscopists.
Endoscopy_UCTN_Code_TTT_1AQ_2AD_3AD
E-Videos is an open access online section of the journal Endoscopy, reporting on interesting cases and new techniques in gastroenterological endoscopy. All papers include a high-quality video and are published with a Creative Commons CC-BY license. Endoscopy E-Videos qualify for HINARI discounts and waivers and eligibility is automatically checked during the submission process. We grant 100% waivers to articles whose corresponding authors are based in Group A countries and 50% waivers to those who are based in Group B countries as classified by Research4Life (see: https://www.research4life.org/access/eligibility/).
This section has its own submission website at https://mc.manuscriptcentral.com/e-videos.
#
Conflict of Interest
The authors declare that they have no conflict of interest.
Acknowledgement
The authors are grateful to the patient for her cooperation.
-
References
- 1 Tsuji K, Yoshida N, Nakanishi H. et al. Recent traction methods for endoscopic submucosal dissection. World J Gastroenterol 2016; 22: 5917-5926
- 2 Kinoshita J, Iguchi M, Maekita T. et al. Efficacy of the traction method for gastric endoscopic submucosal dissection: a randomized controlled trial (with videos). Gastrointest Endosc 2024; 100: 307-311e2
- 3 Grimaldi J, Masgnaux L-J, Lafeuille P. et al. Endoscopic submucosal dissection with adaptive traction strategy: first prospective multicenter study (with video). Gastrointest Endosc 2024; 100: 517-523
- 4 Yamada K, Tajika M, Tanaka T. et al. A novel traction method using a multi-loop traction device in colorectal endoscopic submucosal dissection: anchor traction method. Endoscopy 2024; 56: E780-E781
- 5 Okamura T, Honda T, Ikeda T. et al. Development of a novel multipoint traction device for gastric and colorectal endoscopic submucosal dissection and evaluation of its efficacy and safety. Surg Endosc 2024; 38: 4704-4711
