Peroral cholangioscopy-guided basket extraction of intrahepatic bile duct stones, using a novel thin cholangioscope under balloon enteroscopy, in a patient with Roux-en-Y anatomy

1   Gastroenterology, Saitama Medical University International Medical Center, Hidaka, Japan (Ringgold ID: RIN183786)
,
Shomei Ryozawa
1   Gastroenterology, Saitama Medical University International Medical Center, Hidaka, Japan (Ringgold ID: RIN183786)
,
Masafumi Mizuide
1   Gastroenterology, Saitama Medical University International Medical Center, Hidaka, Japan (Ringgold ID: RIN183786)
,
1   Gastroenterology, Saitama Medical University International Medical Center, Hidaka, Japan (Ringgold ID: RIN183786)
,
Ryuhei Jinushi
1   Gastroenterology, Saitama Medical University International Medical Center, Hidaka, Japan (Ringgold ID: RIN183786)
,
Ryuichi Watanabe
1   Gastroenterology, Saitama Medical University International Medical Center, Hidaka, Japan (Ringgold ID: RIN183786)
,
Ryo Sato
1   Gastroenterology, Saitama Medical University International Medical Center, Hidaka, Japan (Ringgold ID: RIN183786)
› Author Affiliations


Endoscopic stone extraction using a balloon enteroscope in patients with a Roux-en-Y anastomosis is challenging due to the difficulty in aligning the axis between retrieval devices and stones, which often results in failure of stone capture [1] [2]. Recently, it has been reported that a novel thin cholangioscope (EyeMax; Micro-Tech, China), with a length of 219 cm and a diameter of 9 Fr, enables peroral cholangioscopy (POCS)-guided procedures using a balloon enteroscope with a 3.2-mm forceps channel ([Fig. 1]) [3] [4]. Furthermore, it also enables POCS-guided basket extraction. We report a case of successful POCS-guided basket extraction of intrahepatic bile duct stones using a novel thin cholangioscope under balloon enteroscopy in a patient who had undergone a Roux-en-Y procedure.

Zoom Image
Fig. 1 Thin cholangioscope (EyeMax; Micro-Tech, China), length 219 cm, diameter 9 Fr.

A 68-year-old woman who had undergone hepaticojejunostomy with Roux-en-Y construction was referred to us. Computed tomography revealed stones in the intrahepatic bile duct ([Fig. 2]). Although the previous hospital had attempted stone extraction, the stones could not be captured using the basket catheter. Therefore, we performed endoscopic retrograde cholangiopancreatography (ERCP) using a short-type single-balloon enteroscope (SIF-H290; Olympus, Japan) with a working length of 152 cm and a working channel of diameter 3.2 mm [1] ([Video 1]). Cholangiography revealed stones in the intrahepatic bile duct ([Fig. 3]). Subsequently, POCS was performed using a thin cholangioscope, revealing stones in the intrahepatic bile duct ([Fig. 4]). Since the stones were considered difficult to capture, POCS-guided basket extraction was attempted using a retrieval basket (SpyGlass Retrieval Basket; Boston Scientific, USA) ([Fig. 5] a), that could be inserted through the thin cholangioscope. The stones were successfully captured under cholangioscopic visualization ([Fig. 5] b, c). Finally, complete stone extraction was confirmed using the cholangioscope ([Fig. 5] d).

Zoom Image
Fig. 2 Computed tomography revealed stones (arrows) in the intrahepatic bile duct.
Zoom Image
Fig. 3 Cholangiography revealed stones (arrows) in the intrahepatic bile duct.
Zoom Image
Fig. 4 Cholangioscopic view of stones in the intrahepatic bile duct.
Zoom Image
Fig. 5 Cholangioscopic and endoscopic findings. a Retrieval basket (SpyGlass Retrieval Basket; Boston Scientific, USA) that could be inserted through the thin cholangioscope. b, c The stones were successfully captured under cholangioscopic visualization. d Complete stone extraction was confirmed using the cholangioscope.

Quality:
Peroral cholangioscopy-guided basket extraction of intrahepatic bile duct stones, using a novel thin cholangioscope under balloon enteroscopy, in a patient with Roux-en-Y anatomy.Video 1

POCS-guided basket extraction is beneficial for capturing difficult stones, as POCS allows for direct visualization of stones [5]. This thin cholangioscope enables POCS-guided basket extraction under balloon enteroscopy in patients with Roux-en-Y anatomy.

Endoscopy_UCTN_Code_TTT_1AR_2AH

Endoscopy E-Videos https://eref.thieme.de/e-videos

E-Videos is an open access online section of the journal Endoscopy, reporting on interesting cases and new techniques in gastroenterological endoscopy. All papers include a high-quality video and are published with a Creative Commons CC-BY license. Endoscopy E-Videos qualify for HINARI discounts and waivers and eligibility is automatically checked during the submission process. We grant 100% waivers to articles whose corresponding authors are based in Group A countries and 50% waivers to those who are based in Group B countries as classified by Research4Life (see: https://www.research4life.org/access/eligibility/).

This section has its own submission website at https://mc.manuscriptcentral.com/e-videos.


#

Conflict of Interest

The authors declare that they have no conflict of interest.
