Intracranial Cavernomas: An Institutional Review

Abstract

Introduction Intracranial cavernomas are rare vascular malformations accounting for 0.4 to 0.8% of all intracranial lesions. They usually present with seizures and neurological deficits following hemorrhagic episode. Surgical excision can provide lifetime cure from these lesions.

Aims and Objectives The aims and objectives of this study were to study the clinicopathological profile and discuss management strategies affecting the outcome of patients with intracranial cavernomas.

Materials and Methods We have studied patients of intracranial cavernomas operated in our department in the past 5 years. Magnetic resonance imaging of the brain was used as diagnostic modality of choice. Patients' clinical status upon admission and accessibility of the lesion were taken into account for surgical planning.

Observation and Results Most of the patients were young. Twenty-two patients had single and 6 patients had multiple lesions. Patients with supratentorial lesions mainly presented with seizures (75%) wherein infratentorial lesions had cranial nerve palsies and long tract signs (25%). Total surgical excision was achieved in all the patients. No significant postoperative complications were encountered. None of the patient showed recurrence during follow-up period.

Conclusion Patients benefit from modern neurosurgical techniques in contrast to conservative approach in this disease of rather prolonged and unpredictable natural course.

Keywords

cavernoma - surgical excision - intracranial

Introduction

Cavernomas are the clusters of abnormal, hyalinized capillaries surrounded by hemosiderin deposits and a gliotic margin without intervening brain parenchyma. They are low-flow vascular malformations and contain blood products at various stages of evolution. The incidence of intracranial cavernoma is 0.4 to 0.8% in the general population. About 70 to 80% of them are located in supratentorial compartment, while 20 to 30% are in brain stem and cerebellum. Annual risk of hemorrhage is 0.7 to 1.1% per lesion for index bleed, while it increases to 4.5 to 5% per lesion for rebleeding.[1] [2] [3] These are dynamic lesions which can grow, bleed, and regress. They are characterized by ongoing repeated intralesional microhemorrhages which leads to gradual impairment of patients' neurological function, not as dramatically as with hemorrhage due to arteriovenous malformations but often warrants surgical removal.

Magnetic resonance imaging (MRI) of the brain is the diagnostic modality of choice. T₁-weightedand T₂-weighted sequences show variable signals depending on the age of blood products. Popcorn appearance of the lesion is characteristic. It shows rim of signal loss due to hemosiderin deposition and prominent blooming on susceptibility-weighted sequences. However, most of the cavernomas are angiographically occult.[4]

Clinically, benign cavernomas are usually managed conservatively, while the symptomatic superficial lesions are dealt with microsurgical resection. Stereotactic radiosurgery is reserved for deeper lesions. However, conservative management cannot be relied on as natural history of these lesions is unpredictable. Stereotactic radiosurgery is also not promising as there is a persistent risk of bleeding and seizures. However, safe microsurgical excision of these lesions can dissipate the risk of bleeding and seizures.[5] [6] [7] Hence, intracranial cavernoma is a surgically curable cause of epilepsy and cerebral hemorrhage.

Aims and Objectives

The aims and objectives of this study were to study the clinicopathological profile and discuss management strategies affecting the outcome of patients with intracranial cavernomas.

Materials and Methods

We did a retrospective study of 28 patients of intracranial cavernomas operated during January 2011 to December 2015. After thorough clinical examination, patients were subjected to computed tomography (CT) and MRI of the brain with contrast. Tractography and angiography were done wherever indicated. Based on clinical examination and radiological investigations, preoperative planning was done. Surgical approach was decided depending on location of the tumor. Total excision of cavernoma along with peripheral hemosiderin ring was done in all cases. Follow-up was done with MRI of the brain after 3 months and 1 year.

Observations and Results

The observations and results are shown ([Tables 1] [2] [3] [4] [5] [6] [7] [8] [9]), and includes sex-wise distribution ([Table 1]), age-wise distribution ([Table 2]), clinical presentation ([Table 3]), number of lesions ([Table 4]), location of the lesion ([Table 5]), surgical approaches ([Table 6]), extent of resection ([Table 7]), complications ([Table 8]), and outcome assessment ([Table 9]).

Table 1 Sex-wise distribution

	Number of patients	Percentage (%)
Male	17	60
Female	11	40

Table 2 Age-wise distribution

Age (y)	Number of patients	Percentage (%)
1–9	2	7
10–19	7	25
20–29	8	29
30–39	5	18
40–49	3	11
50–59	2	7
60–69	1	3

Table 3 Clinical presentation

Clinical presentation	Number of patients	Percentage (%)
Headache	22	75
Seizures	21	75
Focal neurological deficit	7	25
Hemorhage	7	25

Table 4 Number of lesions

	Number of patients	Percentage (%)
Single	22	78
Multiple	6	22

Table 5 Location of the lesions

Location	Number of patients	Percentage (%)
Supratentorial	18	64
Infratentorial	4	14
Combined	6	22

Table 6 Surgical approach

Approach	Number of patients	Percentage (%)
Frontal/parietal/temporal craniotomy	21	75
Retrosigmoid craniectomy	4	14
Midline suboccipital craniectomy	3	11

Table 7 Extent of resection

Extent of resection	Number of patients	Percentage (%)
Complete	22	78
Incomplete	–	–
Residual asymptomatic multiple cavernomas	6	22

Table 8 Complications

Complications	Number of patients	Percentage (%)
Rebleeding	–	–
Seizures	–	–
New neurological deficit	1	3
Prolong ventilatory support and tracheostomy	2	6
Infection	–	–
Death	–	–

Table 9 Outcome assessment

Outcome parameter	Number of patients	Percentage (%)
Seizure control	7/21	33
Headache	22/22	100
Focal neurological deficit	–	–

Illustrated Cases

Case 1

A 30-year-old man presented to OPD with complaints of headache, imbalance while walking and giddiness of 3 months duration. On clinical examination, he had features of left cerebellar ataxia. MRI of the brain was done which revealed mixed intensity lesions involving left cerebellum, right parietal region, and left centrum semiovale. As the patient was symptomatic with cerebellar lesion, it was excised surgically. Other two cavernomas were left behind. Symptomatic improvement is noted and patient is under regular follow-up ([Figs. 1] [2] [3]).

Fig. 1 T1-weighted axial image.

Fig. 2 T2-weighted axial image showing cavernous malformation in left cerebellar hemisphere.

Fig. 3 Fluid-attenuated inversion recovery image showing right parietal and left frontal cavernoma.

Case 2

A 28-year-old man came with acute-onset right-sided weakness and abnormal deviation of face. On clinical examination, he had right hemiparesis (Power—MRC [Medical Research Council] Grade 2 in both upper and lower limbs with left facial paresis (LMN [lower motor neuron] type—House and Brackmann Grade 4). MRI of the brain was suggestive of two cavernomas in pontine and cerebellar peduncle region on either side, left side lesion showing evidence of hemorhage correlating with clinical presentation. It was targeted during surgery using neuronavigation. Complete excision achieved. Patient recovered gradually and presently under regular follow-up ([Figs. 4] [5] [6] [7]).

Fig. 4 T1-weighted axial image showing two cavernomas in pons and cerebellar peduncle region.

Fig. 5 T1-weighted sagittal image.

Fig. 6 Intraoperative neuronavigation image.

Fig. 7 Histopathological slide showing thinned out vascular parenchyma with intraluminal thrombus.

Case 3

A 34-year-old man presented with acute-onset right-sided weakness and convulsions. Neurologically, he had right-sided hemiparesis (Power—MRC Grade 2) with Glasgow coma scale 15/15 status. MRI of the brain revealed left parietal mixed intensity lesion with perilesional rim of hypointensity with blooming on gradient images. Lesion was localized with neuronavigation and completely excised along with perilesional bleed. Patient's power was Grade 2 in postoperative period and gradually improved in the physiotherapy follow-up period ([Figs. 8] [9] [10]).

Fig. 8 T1-weighted image showing left parietal cavernoma localized on the motor strip.

Fig. 9 T2-weighted image.

Fig. 10 Intraoperative ultrasound image.

Discussion

Cavernous malformations are dilated thin-walled sinusoids covered by single layer of endothelium with undeveloped tight junctions. First report on cavernomas was given by Von Rokitanski in 1846, while first successful removal of cavernous angioma was reported by Bremer and Carson (1890). Natural evolution of cavernomas is totally unpredictable. Repeated hemorrhagic attacks and intractable seizures complicate the natural course.[1] [2] [3] Microsurgical excision of these lesions virtually eliminates the risk of bleeding and seizures. Therefore, microsurgical excision is the definitive treatment in these cases.[8]

Our study encompasses 17 male and 11 female patients with ages ranging between 7 and 62 years. Most of the patients were young. Eighteen patients had supratentorial lesion, while 4 patients had cavernoma positioned in the infratentorial compartment; 6 patients had multiple cavernomas involving both the compartments. Patients with supratentorial lesions mainly presented with seizures (75%), while patients with infratentorial lesion presented with cranial nerve palsies and long tract signs (25%); 25% patients presented with acute hemorrhagic episode and undergone surgery in subacute period after hemorrhage (within 3 weeks).

For supratentorial lesions, keyhole craniotomy was done guided by neuronavigation and marker CT scan. Intraoperative ultrasound was used to accurately localize the lesion and confirm complete excision. Transsulcal approach was preferred. Identification of underlying cavernoma was done by adjacent yellowish discoloration of the brain tissue. Lesionectomy with excision of hemosiderin and gliotic ring was done in all the patients.

In case of posterior fossa lesions, we had four brain stem lesions and three patients with cerebellar lesions. Regarding the approach, “shortest way to the lesions” was favored. Neuronavigation was used to pinpoint the lesion in brain stem. Electrocoagulation shrinkage of the lesion followed by limited internal decompression and piecemeal removal was done.

Thus, total excision was achieved in all the patients. None of them had rebleeding. One patient with brain stem lesion developed additional neurological deficit in postoperative period. Two patients required prolong ventilation and tracheostomy. They were weaned off tracheostomy in 1 month. Follow-up MRI did not show recurrence in any of the patients. Out of 21 patients who presented with seizures, 7 patients became seizure free at the end of 1 year postoperatively.

Conclusion

Cavernomas represent an uncommon but surgically curable cause of epilepsy and cerebral hemorrhage. The use of neuronavigation and intraoperative ultrasound is useful tools in localizing the lesion and planning the approach.
