acetabular fracture - total hip arthroplasty - management of acetabular fractures in the elderly
Operative fixation of displaced acetabular fractures with anatomical reduction has good reported outcomes in the hands of experienced surgeons, but certain patient factors and injury patterns predictably lead to failure of reconstruction and posttraumatic osteoarthritis.[1]
[2]
[3] As the elderly population increases and is more active, orthopaedic trauma surgeons treat more patients older than 60 years with displaced acetabular fractures.[4]
[5] These patients more commonly have poor bone stock, preexisting osteoarthritis, medical comorbidities, and fracture patterns that predictably lead to failure,[5]
[6] complicating operative management of these injuries. Options to treat these injuries include nonoperative management, percutaneous fixation, open reduction internal fixation (ORIF), and ORIF with total hip arthroplasty (THA).
When modern THA was being developed, displaced acetabular fractures were often managed with traction/immobilization or less commonly with limited, open internal fixation. Series of patients with fracture–dislocations of the hip in the 1950s and 1960s treated with these techniques report “mild-to-moderate concessions.”[7] Patients with progressive loss of function were treated with cup arthroplasty or THA. Primary arthroplasty for acetabular fractures was not performed because “the magnitude of operative injury superimposed on the tissue injury from trauma has failed to improve what could be obtained by direct attack on the fracture.”[7] Around the same time, Coventry reported a series of five patients who underwent THA for chronic and subacute fracture–dislocations of the hip.[8] Two patients underwent cemented THA at 3 and 7 weeks after the injury. Otherwise, THA was reserved for late reconstructions of chronically dislocated joints. Coventry described a technique of staged fixation of the acetabulum with removal of the femoral head and THA 5 to 8 weeks after the initial operation. One patient in this series had loosening of the acetabular component.[8] Other studies reported a series of patients treated successfully with mold arthroplasty for acute acetabular fractures.[9]
[10] Despite these reports of a small number of successful cases, early THA for acute acetabular fracture would not widely be considered until the development of the modern press-fit acetabular implant.
Most of the subsequent literature in the 1970s and 1980s focused on the late reconstruction of failed nonoperative or operative treatment of acetabular fractures with posttraumatic osteoarthritis and avascular necrosis of the femoral head. Boardman and Charnley reported the largest series at the time of patients who underwent late reconstruction of a failed acetabular fracture with THA.[11] Their average time from injury to reconstruction was 15 years. Most of these patients were initially treated nonoperatively (81%).[11] These patients were relatively young at the time of reconstruction (54.7 years), and they reported good outcomes with low complication rates. More recent series using press-fit acetabular components report improved functional outcomes for these patients but higher rates of revision surgery at midterm follow-up compared with patients with primary osteoarthritis. Ranawat et al reported a revision rate of 19% at an average of 4.7 years follow-up for various indications including infection, aseptic loosening, and dislocation.[12] Berry and Halasy reported a series of 33 patients with late THA for failed acetabular fracture with minimum 10 years follow-up.[13] Reconstruction was performed for failed ORIF in 44% of cases. Overall, there was a 41% revision rate. Nine (27%) hips underwent revision of the acetabular component. Higher rates of revision surgery in these series compared with patients with primary osteoarthritis allude to the technical difficulty of these late reconstructions even when performed by experienced surgeons and the relatively young age of the patients with increased demand on implants.
In the 1990s, reports of a larger series of patients who underwent successful THA for acute acetabular fracture brought this treatment option to the forefront. Since that time multiple authors have published a series of cases with varying rates of success, but overall reliable outcomes for appropriate indications. Mears and Shirahama published descriptions of the technical aspects of the procedure[14] and later the largest series of patients treated with acute THA for acetabular fracture.[15] The following discusses the indications for early THA in patients with acetabular fracture, clinical outcomes, and technical considerations. Three case examples are included to highlight technical considerations.
Indications for Early Total Hip Arthroplasty in Patients with Acetabular Fractures
Indications for Early Total Hip Arthroplasty in Patients with Acetabular Fractures
Early THA is considered in a small subset of patients with acetabular fractures. Most patients with displaced acetabular fractures are indicated for ORIF, and multiple surgical approaches have been described. For experienced surgeons, satisfactory clinical outcomes have been reliably achieved.[1]
[16]
[17]
Patients who are physiologically and chronologically older offer more complexity for the treating surgeon. In senior patients (older than 60 years), rates of conversion to late THA for failed fixation has been shown to be between 6[16] and 28%.[3] These patients have higher rates of fracture patterns that predictably lead to a failure of fixation.[5] Ferguson et al reported that patients older than 60 years have roof impaction in 40% of cases of anterior column fractures and marginal impaction in 38% of posterior wall fractures.[5] In these older patients, the treating surgeon needs to be able to recognize fracture patterns that will predictably lead to a failure of operative fixation to appropriately indicate early THA.
Posterior wall fractures, isolated and with associated fracture patterns, have rates of failure after operative fixation between 10[18] and 26%,[2] depending on the severity of the initial injury and how the author describes failure. Predictors of failure include comminution of more than three fragments, involvement of the superior dome, and marginal impaction.[2]
[18] Moed et al also found poor results in patients who developed osteonecrosis of the femoral head. Osteonecrosis seen more commonly in patients with greater than 12 hours to closed reduction of a hip dislocation. In older patients with these predictors of failure with ORIF after posterior wall fracture, THA can be considered as a viable treatment option.
In patients older than 60 years, the presence of dome impaction has been shown to be predictive of fixation failure. This is referred to as the “seagull sign” or “gull sign” and is described based on two different fracture patterns. Judet et al described a partial fracture of the posterior column, where the intact posterior column at the articular surface was impacted by the femoral head.[19] This impaction can often be addressed through a posterior approach but is an indicator of osteoporotic bone. Anglen et al in an often-quoted study reported outcomes in a series of patients older than 60 years with fixation of acetabular fracture. They noted that patients with central–superior dome impaction in a high-transverse fracture pattern and central dislocation had a high failure rate.[6] Eighty percent of patients with this radiographic finding did not have anatomical reduction with fixation, and the rate of loss of reduction was high. These impaction injuries indicate more severe articular injury as well as low subchondral bone density, both predictors of failure. They concluded in their paper that THA should be considered in senior patients with a “gull sign.”
Most papers that report a series of patients undergoing early THA for acetabular fractures report similar indications for the operation.[15]
[16]
[20]
[21]
[22]
[23] Elderly patients are a common justification for THA. Generally, a cutoff of 60 years is described, but the physiological age of the patient must be considered. Carroll et al included a useful flowchart to consider when managing senior patients with acetabular fracture.[22] THA was considered when an elderly patient was determined to be able to tolerate surgery, was functional and ambulatory before the injury, and fit the criteria of irreducible fracture, longer planned operation with ORIF only, impaction of the articular surface, displaced femoral neck fracture or femoral head fracture, arthrosis, and severe osteoporosis.[22] Similar inclusion criteria are listed in these series.
Clinical Outcomes for Total Hip Arthroplasty in Acute Acetabular Fractures
Clinical Outcomes for Total Hip Arthroplasty in Acute Acetabular Fractures
Clinical concerns for performing early combined ORIF with THA in patients with acetabular fracture include the magnitude of the operation in elderly patients who are injured and often polytraumatized with preexisting comorbidities, loosening of the acetabular component due to compromised fixation, and dislocation. Overall, reported series of these operations using modern implants and techniques have low complication rates with good function, but complications and reoperation rate are slightly higher than that in patients undergoing THA for osteoarthritis.
Mears and Velyvis reported the largest, most complete series on our literature review.[15] They reported on 57 patients who underwent early THA combined with ORIF for acetabular fracture, with an average follow-up of 8.7 years. The most common complication they reported was heterotopic ossification in 11%. There were no deep infections or mortality related to the surgery. There was mild settling of the acetabular component early (3 mm medially and 2 mm vertically), and no patients suffered nonunion of the fracture or loosening of the acetabular component. Other series also reported settling of the acetabular component.[20] Six patients had excessive medialization of the acetabular cup, as determined by the surgeon, but this was not associated with loosening or pain. There were only two dislocations in the series. One required revision for recurrent dislocations. Multiple series reported a low rate of dislocation. Herscovici et al in a series of 22 patients undergoing the combined procedure reported on two patients who underwent revision for dislocation.[21] In their series, two patients also underwent revision for component loosening. Heterotopic ossification is a common finding in these patients postoperatively. They reported a rate of 21%. Only one patient has grade IV ossification and none elected to have a repeat operation for the heterotopic ossification. Complication rates of early THA for acetabular fracture are summarized in [Table 1].
Table 1
Complication rates reported in a series of early THA for acetabular fracture
|
Author
|
Number of patients
|
Revision at follow-up (%)
|
Heterotopic ossification (%)
|
Acetabular loosing (%)
|
Femoral loosening (%)
|
Dislocation
(requiring revision) (%)
|
Infection (%)
|
Early postoperatively mortality (%)
|
|
Mears and Velyvis[15]
|
57
|
5.3
|
11
|
0
|
0
|
3.5 (1.8)
|
0
|
0
|
|
Herscovici et al[21]
|
22
|
18.2
|
22.7
|
9
|
9
|
13.6 (9)
|
0
|
0
|
|
Beaulé et al[25]
|
10
|
0
|
10
|
0
|
0
|
10 (0)
|
0
|
0
|
|
Mouhsine et al[30]
|
11
|
0
|
27.3
|
0
|
0
|
0
|
0
|
0
|
|
Boraiah et al[20]
|
18
|
5.6
|
5.6
|
5.6
|
5.6
|
5.6
|
5.6
|
0
|
|
Rickman et al[27]
|
24
|
0
|
0
|
0
|
0
|
0
|
4.2
|
4.2
|
|
Sermon et al[28]
|
64
|
8
|
28
|
–
|
–
|
–
|
–
|
–
|
|
Enocson and Blomfeldtet al[26]
|
15
|
0
|
26.7
|
0
|
0
|
0
|
0
|
7
|
|
Lin et al[17]
|
33
|
6
|
27.2
|
3
|
0
|
3
|
3
|
0
|
|
Total
|
254
|
5.9
|
18.5
|
1.6
|
2
|
4.3
|
1.5
|
1.1
|
Abbreviation: THA, total hip arthroplasty.
It should be noted that regardless of timing, THA performed after acetabular fracture demonstrates decreased survivorship and higher complication rates compared with THA performed for primary osteoarthritis or avascular necrosis. Morison et al reports 64 to 78% survival rate at 10 years compared with 90% in hips without previous acetabular fracture in a matched cohort study.[24]
It should also be noted that the surgeons reporting success with this operation all perform a high volume of THA and fixation of acetabular fracture and have teams that are prepared for the magnitude of the operation and its possible complications.
Technical Considerations
Early THA has been described using multiple approaches to the hip. Mears et al reported using three different approaches for the reconstruction and arthroplasty depending on the pattern of the fracture, but they highlighted the advantage of prepping the acetabulum through the anterolateral approach. In their series, the posterolateral approach was used in 28%, anterolateral in 67%, and extended lateral in 5%.[15] They also published the most detailed description of the technical aspects of the operation. Their preferred approach was the anterolateral approach because this allowed for reaming and positioning of the acetabulum without pressure from the anterior soft tissues to misdirect into a retroverted position. The components are placed in the axis of the acetabulum. The resected femoral head is used as a structural bone graft. A multihole press-fit acetabular component allows for the placement of multiple 6.5-mm screws and uses the cup as a “hemispherical plate” to support the fixation.
Herscovici et al reported using an ilioinguinal approach combined with a posterolateral approach in three patients.[21] The indication was the concern that fixation through a posterolateral approach would not sufficiently stabilize the pelvis to support the acetabular component. The pelvis was reduced and stabilized through the ilioinguinal approach with the patient supine and then positioned lateral to perform posterior fixation and THA. Dual approaches were not preferred because of longer operative times and increased blood loss.
Beaulé et al reported the use of an anterior Levine approach for the fixation of an acetabular fracture with anterior THA.[25] This series primarily included anterior column/wall fractures that were best reduced and stabilized through this approach. Series published by Boraiah et al[20] as well as Enocson and Blomfeldt[26] used only the posterolateral approach. Rickman et al primarily used an anterior intrapelvic approach combined with a posterolateral approach for THA.[27] They advocated that their fixation was safe for early weight-bearing with THA. Surgeons should use approaches that they perform often and allow for stable fixation before arthroplasty.
Cable fixation is also described for the fixation of these injuries.[14]
[28] There are reports of safe placement of these fixation devices that allow for the stabilization of the injury to allow for THA. This should not be performed without extensive previous technical experience with this fixation strategy.
Case Examples and Authors' Preferred Management
Case Examples and Authors' Preferred Management
In our practice, early THA for patients with acetabular fracture is uncommon but is strongly considered in older patients with fracture patterns that will predictably lead to failure with ORIF alone. Previous studies at our institution have highlighted patterns with high failure rates, and this is taken into consideration when managing these patients.[2] A review of our patients with operatively treated acetabular fractures identified 14 patients who underwent early THA. During this time period, 215 patients underwent operative fixation without arthroplasty. Early THA was performed acutely in 6.5% of cases with reliable results. Elderly patients with displaced both-column, anterior column, and anterior column fractures that could be mobilized early were treated nonoperatively.
In the evaluation of these patients, the preinjury ambulatory/functional status, preexisting comorbidities, and associated injuries must be carefully considered. As shown in the previously described series, these patients often offer more complexity in the form of preexisting conditions. A similar medical and trauma work-up is performed in patients who have displaced femoral neck fractures in this age group.
Standard work-up in patients with acetabular fracture includes an anteroposterior (AP) pelvis and Judet oblique films taken in the emergency room. Computed tomography (CT) scan is used to assess articular injury and further evaluate fracture pattern. Three-dimensional reconstructions are useful for preoperative planning. After a patient is indicated for early THA, a low AP pelvis radiograph is obtained for templating.
Our patients all undergo screening for Staphylococcus aureus (SA) nasal colonization preoperatively. Patients who are positive for SA colonization are given mupirocin nasal ointment and chlorhexidine washes twice a day for 5 days. Surgery is not delayed for completion of this treatment. Positive screening for methicillin-resistant SA is an indication to add vancomycin to the perioperative antibiotics. Ancef is given to all patients before incision in the operating room. There is evidence that gram-negative coverage should be added to the perioperative antibiotics in patients who are undergoing pelvis surgery,[29] but this is not currently performed in our practice. Enoxaparin or subcutaneous heparin is given, except for the day of surgery, unless contraindicated for deep venous thrombosis prophylaxis.
The indications for early THA in our practice are similar to the previously presented series. Age above 55 or 60 years is often used arbitrarily as an age when arthroplasty should be considered as one of the treatment options, but the physiological age of the patient should be considered, as well as the opinion of the surgeon for the chances of success with open reduction and internal fixation alone. THA can be considered in younger patients with certain failure using standard fixation strategies. Certainly, severe articular comminution or impaction is a predictor of failure as well as significant femoral head injury/fracture. Preexisting osteoarthritis would push toward THA. Osteoporosis is also taken into consideration. In specific patients, the decision to proceed with THA is made intraoperatively after evaluation of the severity of articular injury. This possibility must be discussed with the patient preoperatively.
In patients with comminuted posterior wall fractures indicated for THA, the cup is placed more medially. This allows for more surface area with press-fit fixation on the intact posterior wall and posterior column. In anterior column fractures with bone defects, the femoral head is morselized or used as a structural graft to support the acetabular component. Also, the femoral head is osteotomized prior to fixation to allow for easier reduction and exposure of the acetabulum.
Posterolateral approach is our preferred approach for fixation of the fracture and THA. Extended approaches or dual approaches add significant risk, as shown in other series,[21] and is not required to obtain stability of the pelvis with modern press-fit acetabular components. Multihole acetabular components are used to allow for fixation across the facture and for added stability. In anterior fracture patterns, a portion of the femoral head is occasionally placed in anterior defects either as a structural or morselized graft. The cup is secured to the posterior column. In our experience, adequate stability can be obtained through this approach. In the absence of severe osteoporosis, uncemented femoral components are preferred.
Case 1
A 68-year-old man with a past medical history of hypertension suffered a 12-feet fall from a ladder, resulting in a posterior wall acetabular fracture–dislocation. He had no other injuries. Prior to the injury, he worked in a factory. He had no prior history of hip pain.
Radiographs and CT scan demonstrated a comminuted posterior wall acetabular fracture with marginal impaction ([Figs. 1] and [2]). He was evaluated by the general surgery trauma service as well as medical teams. After a discussion with him regarding the prognosis of the injury and potential treatment options, he underwent open reduction and internal fixation with THA. A standard posterolateral approach was performed. The femoral neck osteotomy was performed and the femoral head was removed. The intact acetabulum was reamed to 1 mm less than the selected implant. The posterior wall fragments were then reduced to the trial acetabulum and fixed using standard techniques for a posterior wall fracture using a nine-hole pelvic reconstruction plate. A standard three-hole acetabular component was used as we had adequate fixation and did not require a multihole cup. The femoral component was placed using standard techniques.
Fig. 1 (a–c) Anteroposterior pelvis and Judet oblique views of the patient presented in case 1.
Fig. 2 (a–d) Computed tomography (CT) scan with three-dimensional reconstruction of the patient presented in case 1.
The patient did well postoperatively. He was last seen in clinic 9 months after the procedure and was having no pain. Postoperative radiographs are shown in [Fig. 3].
Fig. 3 (a–b) Immediate postoperative and 9-month radiographs after reconstruction in case 1.
Case 2
A 79-year-old man with a history of hypertension suffered a 5-feet fall from a ladder resulting in a transverse posterior wall acetabular fracture with central dislocation. He had retired and previously worked as an engineer. He had no previous hip pain or injuries.
Radiographs and CT scan demonstrated a transverse posterior wall fracture with articular comminution ([Figs. 4] and [5]). In this case, the “gull sign” can be seen on both AP and obturator oblique radiographs, indicating an articular injury predictive of failure with operative fixation alone. He is also noted to have joint space narrowing on the contralateral hip indicating preexisting osteoarthritis. He was indicated for ORIF with THA. He was taken to the operating room 4 days after the injury. Again, a standard posterolateral approach was performed. In this case, the transverse fracture was reduced after dislocation and removal of the femoral head. Fixation was performed with a nine-hole pelvic reconstruction plate and a 1/3 tubular plate. After fixation, reaming of the acetabulum was performed. Standard THA was performed with a multihole acetabular component.
Fig. 4 (a–c) Anteroposterior pelvis and Judet oblique views of the patient presented in case 2.
Fig. 5 (a–c) Computed tomography (CT) scan of the patient presented in case 2.
The patient did well postoperatively. He was last seen in clinic 5 years after the procedure and was having no pain. Follow-up radiographs are shown in [Fig. 6]. He was very active and continued to push mow his lawn and do yard work.
Fig. 6 (a–c) Immediate postoperative and 5-year radiographs after reconstruction in case 2.
Case 3
A 62-year-old woman with a past medical history of osteogenesis imperfecta suffered a fall from standing in the bathroom, resulting in a both-column acetabular fracture with central dislocation. She also had a distal radius fracture but no other injuries. She was otherwise healthy and had no preexisting hip pain.
Radiographs and CT scan demonstrated a both-column acetabular fracture with articular comminution and central dislocation ([Figs. 7] and [8]). Again, in this case, the “gull sign” is seen on radiographs. Her case had added complexity due to her osteogenesis imperfecta. She was indicated for ORIF with THA and taken to the operating room 4 days after the injury. The posterolateral approach was performed. The acetabulum was reduced using standard techniques and stabilized using three pelvic reconstruction plates. Despite her soft bone due to osteogenesis imperfecta stable fixation was achieved. The acetabulum was reamed and a multihole cup was placed. Standard press-fit femoral arthroplasty was performed.
Fig. 7 (a–c) Anteroposterior pelvis and Judet oblique views of the patient presented in case 3.
Fig. 8 (a–d) Computed tomography (CT) scan with three-dimensional reconstruction of the patient presented in case 3.
This case was significantly more difficult because of low bone density. At the 2-year follow-up, the cup migrated medially compared with initial postoperative radiographs ([Fig. 9]). The implants were stable at follow-up, and the patient had some posterior pain with increased activities but otherwise was doing well.
Fig. 9 (a–d) Immediate postoperative and 2-year radiographs after reconstruction in case 3.
