Keywords
MDS - CD34 - MK - CD62P - emperipolesis -
TUBB1
Introduction
Myelodysplastic syndrome (MDS) is a malignant clonal disorder of hematopoietic stem
cells, characterized by ineffective hematopoiesis, single or multilineage dysplasia,
and risk of progression to acute leukemia. Both morphological and functional defects
of platelets have been observed in MDS patients, due to the dysplasia of megakaryocytes
(MKs).[1]
[2] Megakaryocytic proliferation/differentiation is a complex process that involves
up/down expression of signaling molecules in the bone marrow (BM) microenvironment.
Acquired or inherited mutations affecting the of MK development have been identified.
RUNX1 mutation is associated with thrombocytopenia, leading to the increased CD34 expression
on MKs. TUBB1 or GATA1 mutation contribute to a selective advantage for the CD34+ clones and abnormal platelet physiology.[3]
[4]
[5]
[6] In general, CD34 expression on the megakaryocytic lineage is limited to promegakaryoblast
or megakaryoblast and declines progressively throughout cell maturation.[7] Recent evidence suggests that a high level of CD34/CD61 dual positive MKs (CD34+CD61+MKs) is associated with lower platelet count, cytogenetic abnormalities, and shorter
survival.[8]
[9]
Clinically, low platelet count is often related to bleeding complications in MDS patients.
However, because classic “platelet generating” MKs are altered by gene mutation, it
is conceivable that platelet function abnormalities may play a role as well. A few
studies have reported that, mainly with platelet activation and aggregation, many
MDS patients demonstrated impaired platelet phenotypes and reduced functions.[10]
[11] Although platelet transfusions have greatly reduced the incidence of major hemorrhagic
complications, refractoriness to infused platelets becomes a major clinical problem.
In this study, we will investigate the pathological characteristics of BM MKs and
their relationship with driver gene mutation, aiming to find the potential molecular
targets in MDS.
Methods
Patients
Patients with MDS were identified at Ruijin Hospital, Shanghai Jiao Tong University
from May 2019 to December 2023. All study participants were diagnosed and classified
according to the World Health Organization (WHO) 2022 classification.[12] The prognostic impact was evaluated with the International Prognostic Scoring Systems-Revised
(IPSS-R).[13] Peripheral blood (PB) collection and BM biopsies were performed on cases after obtaining
written consent. Patient-matched germline reference samples such as oral mucosal cells
and hair with hair follicles were also harvested. Clinical data related to age, blood
count, and BM biopsy at diagnosis were collected from patients' medical records. The
overall survival (OS) was evaluated as disease outcomes, and events were defined as
death. All survival end points were censored at the date of last follow-up when progression
or death was not observed. The research protocol was approved by the Ethic Committees
of Ruijin Hospital, Shanghai Jiao Tong University School of Medicine.
Morphological Evaluation and Immunocytochemistry
All patients had representative BM biopsies, PB and BM aspirate smears available for
evaluation. BM smears were stained with Wright's-Giemsa (Baso Diagnostics Inc, Zhuhai,
China) and observed by light microscopy (BX41, Olympus Corporation, Tokyo, Japan).
For morphologic dysplasia, features of dysmegakaryopoiesis had to be present in at
least 10% of the cells of the respective lineage. Multilineage dysplasia involved
at least 10% of the cells in two or more lineages. Immunohistochemical staining for
CD34 (1:160 dilution; Dako, Glostrup, Denmark) and CD61 (1:100 dilution; Dako, Copenhagen,
Denmark) in MKs was performed on formalin-fixed paraffin-embedded BM biopsy sections
after heat-induced antigen retrieval using the avidin-biotin peroxidase technique.
One hundred MKs or all MKs in the biopsy (if MKs <100) were counted. Percentage of
CD34+ CD61+ MKs was calculated as CD34+ CD61+ MKs/total MKs, CD34+ CD61+ MKs ≥20% were considered as high-level or positive, and cases with CD34+ CD61+ MKs <20% were considered as negative.
Enzyme-Linked Immunosorbent AssayBM samples were harvested from MDS patients. BM fluids
were obtained by centrifugation of 3,500 × g for 15 minutes. Levels of S100A9 proteins
in the BM fluids were measured using human S100A9 enzyme-linked immunosorbent assaykits
(R&D Systems) according to the manufacturer's instructions.
Platelet Phenotyping and Function Analysis
Washed platelets in Tyrode's buffer at a concentration of 3 × 108/mL was performed as previously described.[14] Platelet aggregation was analyzed at 37°C using a Platelet Aggregation Profiler
(Chrono-Log, Havertown, Pennsylvania, United States). Three independent experiments
were performed to ensure the accuracy of the experimental results obtained. Washed
platelets were preincubated with peptides (250 μM) at 37°C for 30 minutes, stimulated
for 3 minutes with or without thrombin (0.1 U/mL) at 37°C, and immediately fixed with
1% paraformaldehyde. The fixed platelets were labeled with a PE-CD62P and FITC-Annexin
V antibody (BD, Franklin Lakes, New Jersey, United States) at concentrations recommended
by the manufacturers. The same conjugated nonspecific isotype IgG was used as a negative
control. CD62P and Annexin V surface expression were analyzed by flow cytometry. All
the samples were analyzed or stored properly within 2 hours of sampling as recommended
to avoid significant artifacts in platelet analysis and the release of cell microparticles
due to storage.
DNA Extraction and Targeted Next-Generation Sequencing of Megakaryocytes
BM mononuclear cells were obtained by centrifugation on a Ficoll–Hypaque at a density
gradient of 1,500 × g for 25 minutes and then washed three times in phosphate-buffered
saline. Genomic DNA was isolated from bone marrow mononuclear cells and was extracted
by Qiagen blood extraction kit (Qiagen, Hilden, Germany) following the manufacturer's
protocol. DNA quality was assessed by agarose gel electrophoresis and NanoDrop 2000
spectrophotometer (Thermo Fisher Scientific, Wilmington, Delaware, United States).
Targeted amplicon-based NGS of up to 20 MK genes were performed. DNA samples were
subjected to targeted genome sequencing using Illumina HiSeq2000. As previously described,[15] we established filters for the pathogenic versus nonpathogenic call algorithm to
determine clinically actionable pathogenic alterations and to exclude benign variants
or polymorphisms.
RNA Isolations and RNA-Sequencing of Megakaryocytes
Ten milliliters of fresh BM, which had been collected in EDTA tubes, was processed
within 6 hours after collection and stored at 4°C. Nucleated BM cells were separated
over a discontinuous Percoll gradient. After Percoll gradient centrifugation, the
cells were washed with phosphate buffered saline and resuspended in RPMI 1,640 medium
with 0.1% bovine serum albumin. The cells were stained with antihuman CD41-allophycocyanin,
and CD41+ MKs were separated using a FACS Aria cell sorter (BD Biosciences). After washing
and centrifugation, 1 mL of Trizol (Life Technologies, Carlsbad, California, United
States) was added and mixed thoroughly. After extracting total RNA, we used Nanodrop
(Thermo Fisher Scientific, Waltham, Massachusetts, United States) and Qiaxcel (QIAGEN,
Hilden, Germany) to detect the concentration and purity of the extracted RNA. The
samples of total RNA (1 µg) were treated with Ribo-off ribosomal RNA (rRNA) Depletion
Kit (Vazyme, Nanjing, China) before the RNA-sequencing libraries were constructed.
The RNA-sequencing libraries were prepared using the VAHTS Total RNA-seq (H/M/R) Library
Prep Kit for Illumina following the manufacturer's instructions (Vazyme, Nanjing,
China). Annotations of mRNA in the human genome were retrieved from the GENCODE V29
(https://www.Gencodegenes.org/human/release_19.html). The genes that were differentially expressed between groups were analyzed using
a t-test. The most differentially expressed genes were investigated for their involvement
in Kyoto Encyclopedia of Genes and Genomes (KEGG) pathways (https://www.genome.jp/kegg/) using the Database for Annotation, Visualization and Integrated Discovery (DAVID)
v6.8 (https://david.ncifcrf.gov/). The enriched pathways were filtered with p-values <0.01. Preranked gene set enrichment analysis (GSEA) was run on the ranked
list using the Molecular Signatures Database (MSigDB) (https://www.gsea msigdb.org/gsea/msigdb/) as the gene sets.
Quantitative Reverse Transcription Polymerase Chain Reaction
Total RNA was extracted from CD41+ MKs using RNAiso Plus reagent (Takara, Shiga, Japan), and 1.5 µg total RNA from cultured
cells was reverse transcribed using a PrimeScriptP RT Reagent Kit (Takara) according
to the manufacturer's instructions. RT-qPCR was performed using a 7,500 Fast Real-Time
PCR System (Applied Biosystems, Foster City, California, United States). The amplified
transcript level of each specific gene was normalized to that of GAPDH.
Statistical Analysis
Statistical analysis was performed using SPSS statistics 24.0 (SPSS) and R statistical
software. Results were expressed as means ± standard error. The Kolmogorov–Smirnov
test was used to check for the normal distribution of data, and statistical differences
between groups were observed using a t-test or the Mann–Whitney test. The Kaplan–Meier curve was performed and the log-rank
test was applied to estimate and compare OS between the two groups. The level of significance
was p < 0.05 for all analyses.
Results
Patient Cohort: Clinical Characteristics
The clinical characteristics of MDS patients were summarized in [Table 1]. MDS subtypes according to the WHO 2022 classification included MDS with low blasts
(39.42%), MDS with increased blasts type 1 (33.65%), MDS with increased blasts type
2 (12.5%), MDS hypoplastic (6.73%), MDS with fibrosis (5.77%), MDS with biallelic
TP53 inactivation (0.96%), and MDS with low blasts and SF3B1 mutation (0.96%). The
IPSS-R risk distribution was very high (15.38%), high (33.65%), intermediate (30.77%),
and low (20.19%). Among 104 MDS cases, the median age at diagnosis was 64 years (range:
22–84 years). The median BM blasts, absolute neutrophil count, and hemoglobin were
5.00% (range: 0.19–17.00%), 1.78 × 109/L (range: 0.10–29.95 × 109/L), and 67.00 g/L (range: 9.00–153.00 g/L), respectively. Twenty-four cases (24/104,
23.1%) showed a positive expression of CD34 on MKs (28.00%, range: 21.00–80.00%),
and 45.83% (11/24) of them had the emperipolesis phenomenon between MKs and neutrophils.
In the BM of these patients, 20 to 50% of MKs contained neutrophils and neutrophil-specific
myeloperoxidase-positive granules were found within the MK cytoplasm near emperipolesis
neutrophils ([Fig. 1]). During follow-up, 39 (39/104, 37.50%) deaths were recorded.
Table 1
Clinical characteristics of 104 MDS patients according to the MK mutation status
|
With MK mutation
(n = 40)
Median (Min–Max)
|
Without MK mutation
(n = 64)
Median (Min–Max)
|
p-Value
|
|
Age, years
|
64.00 (22.00–79.00)
|
63.50 (22.00–84.00)
|
0.810
|
|
Male, n (%)
|
22 (55.00%)
|
43 (67.19%)
|
0.212
|
|
Neutrophil count, ×109/L
|
1.81 (0.10–15.05)
|
1.64 (0.13–29.95)
|
0.789
|
|
Hemoglobin, g/L
|
61.50 (37.00–100.00)
|
68.00 (9.00–153.00)
|
0.023
|
|
Platelet, ×109/L
|
77.50 (8.00–420.00)
|
102.00 (14.00–936.00)
|
0.044
|
|
BM blast, %
|
5.00(0.5–19.00)
|
5.00 (0.50–17.00)
|
0.826
|
|
CD34+ CD61+ MK, %
|
10.00 (1.00–72.00)
|
4.00 (1.00–80.00)
|
0.012
|
|
Emperipolesis, n (%)
|
8 (20.00%)
|
3 (4.69%)
|
0.032
|
|
Diagnosis, n (%)
|
|
|
0.452
|
|
MDS-h
|
4 (10.00%)
|
3 (4.69%)
|
|
|
MDS-LB
|
16 (40.00%)
|
25 (39.06%)
|
|
|
MDS-IB1
|
13 (32.50%)
|
22 (34.38%)
|
|
|
MDS-IB2
|
5 (12.50%)
|
8 (12.50%)
|
|
|
MDS-f
|
1 (2.50%)
|
5 (7.81%)
|
|
|
MDS-SF3B1
|
0 (0%)
|
1 (1.56%)
|
|
|
MDS-biTP53
|
1 (2.50%)
|
0 (0%)
|
|
|
IPSS-R, n (%)
|
|
|
0.156
|
|
Very high
|
9 (22.50%)
|
7 (10.94%)
|
|
|
High
|
16 (40.00%)
|
19 (29.69%)
|
|
|
Intermediate
|
9 (22.50%)
|
23 (35.94%)
|
|
|
Low
|
6 (15.00%)
|
15 (23.44%)
|
|
|
OS, months
|
33.00 (3.00–65.00)
|
39.00 (12.00–78.00)
|
0.013
|
Abbreviations: BM, bone marrow; IPSS-R, International Prognostic Scoring Systems-Revised;
Max, maximum; MDS, myelodysplastic syndromes (neoplasms); MDS-biTP53, MDS with biallelic
TP53 inactivation; MDS-f, MDS with fibrosis; MDS-h, MDS hypoplastic; MDS-IB1/2, MDS
with increased blasts type1/2; MDS-LB, low blasts; MDS-SF3B1, MDS with low blasts
and SF3B1 mutation; Min, minimum; MK, megakaryocytes; OS, overall survival.
Bold: p<0.05.
Fig. 1 Emperipolesis in CD34+ CD61+ megakaryocytes (MKs). (A) The “rose cluster” phenomenon formed by MK and neutrophils (red arrow). (B) Neutrophils passing through the cytoplasm of MK (red arrow). (C and D) POX particles inside the cytoplasm of MK (red arrows).
Genes Mutation Associated with Megakaryocytes in Myelodysplastic Syndrome
Gene mutation associated with MKs was found in 40 patients. The most frequent mutation
included TUBB1 (11.54%), VWF (8.65%), and NBEAL2 (5.77%), and the common mutation was RUNX1 (3.85%), GFI1B (3.85%), JAK2 (3.85%), ITGA2B (2.88%), ITGB3 (2.88%), ANKRD26 (2.88%), CD36 (1.92%), GP9 (0.96%), MPL (0.96%), and FLNA (0.96%). TUBB1 mutation was found in 12 cases, including eight single nucleotide variants: p.(R307H),
n = 5; p.(Q43P), n = 3; p.(Q43H), n = 1; p.(L273F), n = 1; p.(I377L), n = 1; p.(G38R), n = 1; p.(T149P), n = 1; p.(R318W), and n = 1. In all MDS patients, TUBB1 p.(R307H) and p.(Q43P) mutation was the most common point mutation. NBEAL2 p.(S2054F), VWF p.(G1172V), GFI1B p.(L262P) mutation was found in six cases (5.77%), six cases (5.77%), and three (2.88%)
cases, respectively.
When the clinical features of patients with or without MK mutation were compared,
we found that patients with MK mutation showed similar myeloblast numbers (4.25 vs.
5.00%, p = 0.457) and absolute neutrophil count (1.81 ×109/L vs. 1.64 ×109/L, p = 0.789). However, they presented a higher proportion of CD34+ CD61+ MKs (10.00 vs. 4.00%, p = 0.012) and shorter OS (33.15 vs. 40.50 months, p = 0.013). We evaluated the relationship between MK mutation and CD34+ CD61+ MKs proportion and found that 16 patients with MK mutation showed a high proportion
of CD34+ CD61+ MKs, and half of them had increased emperipolesis of neutrophils. Further, patients
with MK mutation were divided into two subgroups (group A: CD34+ CD61+ MKs ≧20.00%, n = 16; group B: CD34+ CD61+ MKs <20.00%, n = 24). The average percent of CD34+ CD61+ MKs was 29.00% (range: 23.00–49.00%) and 4.00% (range: 2.00–6.00%). Patients in the
group A had lower platelet counts (36.00 ×109/L vs. 88.50 ×109/L, p = 0.015), more profound emperipolesis (8 cases vs. 0 case, p = 0.001), and lower hemoglobin level (59.50 vs. 67.00 g/L, p = 0.030). Moreover, soluble S100A9 in BM fluids was elevated (group A vs. group B,
51.42 vs. 7.76 ng/mL, p < 0.001); notedly, patients with emperipolesis showed markedly higher S100A9 level
(88.80 vs. 29.67 ng/mL, p = 0.010) than others without emperipolesis.
Platelet Function
Platelet function was studied in 70 cases (platelet count: 105.50 ×109/L, range: 48.00–936.00 ×109/L). Platelet aggregation with ADP was defective in 38 patients (38/70, 54.29%), whereas
aggregation with collagen or arachidonic acid was normal for all patients ([Fig. 2A]). In total, 22 patients with MK mutation (22/27, 81.48%) had ADP-induced platelet
aggregation defects, and 13 of them (13/22, 59.09%) developed platelet transfusion
refractoriness (PTR) during the first cycle of chemotherapy. Sixteen patients without
MK mutation (16/43, 37.21%) had ADP-induced platelet aggregation defects, and two
of them (2/16, 12.50%) developed PTR. To quantify the platelet reactivity, we measured
the fraction of activated platelets before and after thrombin-induced stimulation.
Unstimulated platelets from patients with MK mutation had a high expression of CD62P
(53.50 vs. 41.10%, p = 0.001) and Annexin V (13.70 vs. 2.25%, p = 0.001) ([Fig. 2B]). When platelets from patients with MK mutation were activated by thrombin, they
had a higher share of Annexin V on the surface (patients with MK mutation vs. patients
without MK mutation, 85.80 vs. 6.40%, p = 0.002) ([Fig. 2C]).
Fig. 2 Platelet aggregation and activation. (A) Platelet aggregation function in myelodysplastic syndromes patients with or without
megakaryocyte mutation. (B) The expression of CD62P and Annexin V on unstimulated platelet surface. (C) The expression of CD62P and Annexin V on stimulated platelet surface.
RNA-Sequencing of Megakaryocytes
We further explored the transcriptional heterogeneity of specific MKs status. Among
10,643 mRNA that were detected, 4,826 were differentially expressed in patients with
MK mutation. Within these 4,826 mRNA, 269 were continuously upregulated and 4,557
continuously downregulated in group A. Gene ontology (GO) analyses suggested that
the differentially expressed genes were associated with chromatin modification, DNA
repair, transcriptional regulation, programmed cell death, and other important functions.
Further investigation of these processes showed that platelet formation and function
were the core processes of the GO tree ([Fig. 3A]). Increased expression of MKs genes, not just in the intracellular proteins (PKM,
VWF, and FLNA), but also cell surface antigens (CD36, ITGB1, and ITGB3), was noted.
KEGG pathway analyses suggested that innate immune responses, RNA splicing, and mRNA
processing were most enriched among the differentially expressed genes ([Fig. 3B]). GSEA analysis identified that platelet function, platelet aggregation, and platelet
activation pathways were upregulated the most ([Fig. 4]). We focused on several candidate mRNA and verified the changes in their expression
levels, and qRT-PCR assays showed that levels of CXCL10, CD62P, and S100A9 were remarkably
increased ([Fig. 5]).
Fig. 3 Characterization of protein-coding RNA in megakaryocytes (MKs). (A) A heatmap showing distinctly defined expression profiles of mRNA in MKs. (B) Kyoto Encyclopedia of Genes and Genomes pathway analysis in MKs.
Fig. 4 Enrichment plots from gene set enrichment analysis of MKs. (A–D) Gene set enrichment analysis (CSEA) results showing upregulated pathways. (A) Platelet aggregation, normalized enrichment score (NES) = 2.50, p < 0.0001. (B) Homotypic cell–cell adhesion, NES = 2.50, p < 0.0001. (C) Regulation of platelet activation. NES = 2.47, p < 0.0001. (D) Protein activation cascades NES = 2.09, p < 0.0001. (E–H) GSEA results showing downregulated pathways. (E) TNFA signaling, NES = −2.1, p < 0.0001. (F) Interferon alpha response, NES = −2.09, p < 0.0001. (G) Interferon-gamma signaling, NES = −2.03, p < 0.0001. (H) IL6-JAK-STAT3 signaling, NES = −1.79, p < 0.0001.
Fig. 5 Reverse transcription polymerase chain reaction analysis of the potential gene targets
in MDS with MK mutation. (A) The level of CXCL10 gene expression. (B) The level of CD62P gene expression. (C) The level of S100A9 gene expression.
Discussion
MDS is characterized by multiple clonal hematopoietic defects, and some patients may
present with isolated thrombocytopenia and megakaryocytic dysmorphia or atypia. The
development and differentiation from MKs to platelets are revealed to be a complex
process that can be driven by a number of genes. With the advent of next-generation
sequencing, an increasing number of genes associated with megakaryocytopoiesis have
been elucidated. In our present study, the most frequent mutation in MDS included
TUBB1, NBEAL2, and VWF gene. TUBB1 mutation was commonly found to disrupt the normal assembly of microtubules and contributed
to the accumulation of DNA damage and genetic instability.[16]
[17]
NBEAL2 mutation was associated with a genetic disturbance of MK differentiation, with 36
to 65% of MKs containing neutrophils.[18]
[19]
VWF mutation resulted in a reduced number of platelets by MKs, the ectopic release of
platelets in the BM, and the increased clearance of platelet-VWF complexes.[20] Regardless of age and IPSS-R score, patients with MK mutation were at increased
risk of developing thrombocytopenia and/or platelet dysfunction during their lifetime.[21]
[22] Therefore, early recognition of MK mutation in MDS patients could permit appropriate
treatment and adequate monitoring for disease progression.
MK mutation was associated with high levels of CD34 on MK, which was likely a result
of dysplastic maturation committed to the megakaryocytic lineage. Indeed, previous
studies had documented that GATA1, TP53, and RUNX1 genes were related to the high-level expression of CD34 on MKs. The most recently
discovered gene was GFIB, which repressed the CD34 promoter at a direct transcriptional level, and this repression
was attenuated by gene mutation.[23]
[24]
[25] The enhanced emperipolesis in patients with a high percent of CD34+ CD61+ MKs was of interest. Petzold et al confirmed that neutrophils can “pluck” on MKs
to tune platelet release in BM. In Pierre Cunin's model system, they demonstrated
that neutrophil membranes transfer to MKs' demarcation membrane system during emperipolesis.
Receptor–ligand pairs mediating the observation between neutrophils and MKs have been
found in many studies, such as CXCR4–CXCL12, CD18–ICAM-1, or PSGL-1–CD62P.[26]
[27]
[28]
[29] Our data found that CD34+ CD61+ MKs with emperipolesis exhibited hyperreactivity and immature immunity, epitomized
by increased CD62P, CXCL10, and S100A9 transcripts. Together these results implied
a mechanistic role of emperipolesis on MK differentiation, and defective platelet
formation maybe associated with “pathological emperipolesis” in MDS patients with
high levels of CD34+ CD61+ MKs.
Bleeding complications, as a major cause of morbidity and mortality, are commonly
seen in MDS patients. There may be bleeding episodes of varying severity, and there
are variable platelet aggregation defects correlated with poor prognosis. A study
of 75 MDS cases showed defective platelet activation and increased apoptotic platelets
consistent with defective platelet production.[10] Another study observed that ADP was one of the most common agonists with the platelet
aggregation defect and confirmed that defective platelet aggregation was strongly
related to MDS of worse prognosis.[11] These results were consistent with our findings in patients with MK mutation, especially
with high levels of CD34+ CD61+ MKs. These patients showed a decrease in ADP-induced platelet aggregation and an
increase in platelet proactivation and apoptotic platelets. Managing bleeding due
to dysfunctional platelets was based on general principles, and the most studied intervention
was the transfusion of “normal” platelets.[30] However, it may not be effective in major bleeding, for example, intracranial hemorrhage.
To make matters worse, one study suggested that platelet transfusion was instead associated
with higher rates of adverse events and death.[31] In the present study, PTR was increased for MDS patients with MK mutation. Future
studies will expand the sample size and focus more on exploring the relationship between
MK mutation and the molecular etiology of PTR.
In summary, our study was performed to characterize a poor prognostic factor in MDS
patients. We presented evidence that (1) the most common point mutation was TUBB1 p.(R307H) and p.(Q43P), followed by NBEAL2 p.(S2054F) and VWF p.(G1172V); (2) MK mutation was associated with the high percent of CD34+ CD61+ MKs; (3) platelet formation and platelet function were commonly affected by MK mutation;
(4) CD62P, CXCL10, and S100A9 may be the potential targets in patients with MK mutation.
Further studies are no doubt required to evaluate the molecular link between gene
defects and platelet production and to establish any prognostic value.
